9613012 COMO BL d0320mm PC 1x79W 100° 13800lm
COMO BL d0320mm PC 1x79W 100° 13800lm, 4000K, class I, without TW, RAL 9003, IP65. Efficient COMO BL LED high bay spotlight: compact, BEG-compliant, low glare (UGR ≤ 20), versatile installation and ideal for industry, logistics and cold stores.
- affordable LED highbay
- has a Casambi-ready interface
- Spotlight can be controlled and dimmed without additional wiring
- Housing made of aluminum alloy, white powder coated
- cover lenses with optimal inner structure for glare limitation made of PC
- low glare due to internal prismatic lenses UGR<19
technical data
| Dimensions (L x W x H) | 320 x 320 x 123 mm |
|---|---|
| Luminous flux | 13800 lm |
| Performance | 79 W |
| Luminous efficacy | 175 lm/W |
| Color temperature | 4000 K |
| Beam angle | 100 ° |
| Guarantee | 5 years |
| D marking | Yes |
| Supply voltage | AC/DC |
| Market indicator | CE |
| Through-wiring | without |
| Outdoor area | Protected outdoor area* |
| Vandalism protection | No |
| Animal husbandry | not suitable |
| Multi-Lumen | No |
| Length | 320 mm |
| Color rendering Ra | 80 |
| Color tolerance (SDCM) | 5 |
| Glare rating (UGR 4H 8H) | 26.3 / 26.3 |
| IP protection class | IP65 |
| IK Impact resistance | IK08 |
| Protection class | SK I |
| Temperature range | -40 ... +50 °C |
| Lifetime L70B50 (@Ta 25°C) | 102126 h |
| Lifetime L80B50 (@Ta 25°C) | 64642 h |
| Lifetime L90B50 (@Ta 25°C) | 31713 h |
| Lifetime L70B10 (@Ta 25°C) | 87091 h |
| Lifetime L80B10 (@Ta 25°C) | 55442 h |
| Lifetime L90B10 (@Ta 25°C) | 27424 h |
| Lifetime L70B50 (@Ta max) | 102126 h |
| Lifetime L80B50 (@Ta max) | 64642 h |
| Lifetime L90B50 (@Ta max) | 31713 h |
| Line protection B16A | 13 Luminaires |
| Line protection C16A | 22 Luminaires |
| Surge voltage resistance L/N-PE | 6.0 kV |
| Rated voltage / frequency | 220-240V 50/60 Hz |
| Emergency lighting suitability | No |
| REACH | No |
| Interchangeability of operating device | not interchangeable |
| Interchangeability of light source | yes, by specialist(s) |
| Ambient temperature (min) | -40 °C |
| Ambient temperature (max) | 50 °C |
| Certification mark | ENEC |
| Energy efficiency class Light source | B |
| Dimming/Control | Fixed Output |
Tender text
More efficient High Bay COMO BL d0320mm PC 1x79W 100° 13800lm 4000K, class I, without TW, RAL 9003, IP65. Efficient COMO BL LED high bay spotlight: compact, BEG-compliant, low glare (UGR ≤ 20), versatile installation and ideal for industry, logistics and cold stores. Item number: 9613012 GTIN: 4018098409076 Technical details/specification: Cover made of PC - Polycarbonate; Housing made of Aluminium White RAL9003; 220–240V 50/60 Hz; Energy efficiency class B; Number of light sources / LED rows: 1; IP65; Through-wiring in mm²: without; Dimensions: LxWxH: 320mm x 320mm x 123mm; Diameter: 320mm
